iSM-IMX326

The iENSO MIPI sensor module iSM-IMX326 is superbly adaptable to iENSO’s embedded ecosystem of SOMs, camera modules, and wireless connectivity modules.

The iSM-IMX326 uses SONY’s IMX326 sensor with STARVIS technology. STARVIS technology applies a back-illuminated pixel structure, which is more efficient in collecting light to reach high sensitivity and realize high quality in the visible-light and near-infrared light regions.

The SONY IMX326 sensor features a type 1/2.9” color CMOS with 6.8M effective pixel to achieve 3086 x 2196 resolution with digital overlap HDR supported and it’s suitable for various types of iENSO lenses.

Attributes:

Partner

Sony

Sensor Type

Rolling Shutter

Megapixels (MP)

6

Optical Format (inch)

1/2.9

Pixel Size (μm)

1.62

Frame Rate (fps)

30

Benefits

BSI, HDR, Near IR Enhanced

Key Specifications:

  • Framerate: 30 fps at 12 bits (60 fps at 10 bits) over 4 lane MIPI CSI 2 10/12 bit interface.
  • Pixel details: 1.62 μ m, 3072 x 2160 array (approx. 3:2), Exmor R / STARVIS BSI, DOLHDR, rolling shutter.
  • Package/Environmental: ceramic LGA with 92 pins
  • Operating temperature: -10°C to 60°C sensor ambient .
