The iENSO MIPI sensor module iSM-JXF22 is a cornerstone of iENSO’s embedded ecosystem of SOMs, camera modules, and wireless connectivity modules.

The iENSO iSM-JXF22 uses Silicon Optronics’ JX-F22 sensor, which consists of a 1932 x 1088 active pixel sensor (APS) array with on-chip 10-bit ADC, programmable gain control (PGA), and correlated double sampling (CDS) to significantly reduce fixed pattern noise (FPN). The sensor also has many standard programmable and automatic black level calibration functions(ABLC).

The Silicon Optronics JX-F22 sensor features a type 1/2.7” color CMOS with 2M effective pixel to achieve 2 MP resolution, which performs perfectly with iENSO’s multiple types of lenses.

Suggested next generation sensor module: iSM-IMX462



Silicon Optronics

Shutter Type


Max. Resolution (MP)


Optical Format (inch)


Pixel Size (µm)

3.0 x 3.0


HDR, Low Light

Frame Rate (max.)

60fps 10bit



Key Specifications:

  • Framerate: 2M, 60 fps (30 fps in 2-frame HDR mode) over a 4-lane MIPI CSI-2 10-bit interface.
  • Pixel details: 3 μm, 1932 x 1088 array (16:9), color, front illuminated, HDR, rolling shutter.
  • Package/Environmental: wafer-level CSP. Junction temp. range -30°C to 85°C (60°C stable image).
  • Form factor: 26x26 mm

    Contact us to discuss pricing and integration:
