iSM-OV8865

The iENSO iSM-OV8865 is the quality leader MIPI sensor module that adapts to iENSO’s embedded ecosystem of SOMs, vision systems, and wireless connectivity modules.

The iSM-OV8865 uses OmniVision’s OV8865 sensor, offering automatic black level calibration and two on chip PLLs, which result in superior high and low light images and make it perfect for embedded vision system application.

The OV8865 sensor features a type 1/3.2” color CMOS with 8MP effective pixel to achieve 4K UHD resolution with backside illumination technology and it’s suitable for various types of iENSO optimized lenses.

Attributes:

Partner

Omni Vision

Sensor Type

Rolling Shutter

Megapixels (MP)

8

Optical Format (inch)

1/3.2

Pixel Size (μm)

1.4

Frame Rate (fps)

30

Benefits

BSI

Key Specifications:

  • Framerate: 30 fps 1080p at 10 bits over 4-lane MIPI CSI-2 interface.
  • Pixel details: 1.4 μm, 3264 x 2448 array (4:3), automatic black level calibration, rolling shutter.
  • Fits into industry standard 8.5 x 8.5 x 5 mm package.
  • Operating temperature: ambient 10°C to 60°C with built-in sensor.
  • Form factor: 26x26 mm
